Pik'r | Golf Ball Picker Robot

Pik’r™ – First to automate existing standard 3 and 5 gang ball pickers

Autonomously pick up to 4000 balls per round

Pik’r™ - Heavy Duty High Capacity Golf Ball Picking Robot

Description

Korechi Innovations Inc. presents their first robot for the golf industry – the Pik’r™, a dedicated golf ball retrieval robot. This product was first tested in 2019, and since then has been rigorously tested and perfected at several driving ranges.

The Pik’r™ is the world’s first robot that automates existing standard 3 and 5 gang golf ball picking machines at any driving range with turf-grass or artificial turf, which means that it can pick up to 4000 balls per round or about 52,000 balls per 13-hour shift. This automated golf ball picker machine is designed to alleviate the labor shortage that the industry is facing while enhancing the safety of operations. The Pik’r™ is all-electric and runs on safe and long-lasting lithium batteries and can cover up to 7 acres per hour. It is guided by high-precision GNSS RTK sensors with sub-inch accuracy. It uses a camera with Artificial Intelligence to detect and avoid obstacles. Use the provided rugged tablet computer with the RoamIO-MLT™ software to remotely control Pik’r™ from anywhere in the world, generate paths and schedule golf ball picking for the entire day.

Specifications

Body: Powder-coated welded steel tubing chassis + stainless steel & impact-resistant polymer cover

Traction: 18” turf tires

Dimensions: 83” x 55” x 36” (2.1m x 1.4m x 0.9m) (LxWxH)

Weight: Up to 860 lb (390 kg)

Maximum Speed: 4.3 mph (7 kph)

Coverage: Up to 4.1 acres (3 gang) and 7 acres (5 gang) per hour

Capacity: Up to 2400 balls (3 gang) and 4000 balls (5 gang) per round

Motors: Brushless DC

Collision Avoidance: Camera using artificial intelligence + physical and remote e-stop

Battery: Up to 13 hours continuous run time; safe lithium chemistry with 10+ years of life

Positioning: Multi-constellation multi-band GNSS RTK with dual antenna for cm level accuracy

Optional Accessories: Additional batteries, LED floodlights, Structural mounts for sensors and implements, customizable colors

Pik’r™ - automated golf ball picker machine

Pik’r™ Benefits

Save Money & time

Reduces up to 90% labor and material input needed to perform repetitive, tedious tasks. Allows the operator to reallocate their valuable time to more productive tasks while reducing maintenance needs.

Safe & Productive Workplace

Equipped with advanced obstacle detection capabilities for full autonomy, reduces the time workers spend in hostile environments like driving ranges and extreme heat or cold.

Supervise Remotely

Operated using the provided tablet computer via a local Wi-Fi connection or remotely, using our cloud services through cellular connectivity anywhere in the world.

Seamless Integration

Equipped with adapters that directly work with your existing 3 and 5 gang pickers and acts as a drop-in replacement for caged gas-powered UTVs. No modification of existing machinery or facility required.

Seamless Communication

Equipped with artificial intelligence, which enables you to use voice queries to request relevant information. Additionally, Pik’r™ also communicates relevant status & operational information through speech.

Convenient Mission Control

Use the in-app calendar to schedule tasks ahead of time with the peace of mind that Pik’r™ will start its missions punctually while accommodating to your busy schedule.

Friendly With Your Field and the Environment

Being a battery powered electric robotic platform, Pik’r™ reduces your emissions, with potential for carbon credit earnings. Very low soil compaction reduces the need for frequent soil aeration.

Photo Gallery

We are now taking orders

Have inquiries or Demo Requests?

Get in contact with our team, and we’ll gladly assist you.
